Optimal protection
of your pump

Application:

Suction filters protect the downstream hydraulic-pump from coarse contamination, mainly due to lack of initial cleaning or to an accidental ingression.
They take care of the pump, ensuring a safe and efficient operation.
Suction Filters must be properly sized to avoid the cavitation of the pump. A proper filter media selection is highly recommended.
Although these filters play an important role in the hydraulic circuit, the general cleanliness level required by the system must be ensured by additional filters having that function, as Return or Pressure fiIters.

User Benefits:

Suction filters represent the “first-line” filtration and are used to:

  • avoid the ingress of contamination into the hydraulic circuit
  • prolong the lifetime of finer downstream filtration
  • reduce the particulate-load on the finer filter, thus extending servicelife-intervals, unplanned downtime and maintenance
  • avoid damage to the finer downstream filter from coarse particulate, such as rust

CAL

In-line suction element

Materials

Housing: Zinc plated steel

Working temperature

From -25° to +110° C

Flow rate

Up to 100 l/min

Download

ESA – ESB

Suction strainer

Materials

Connector: Polyamide
(Aluminum for ESA & ESB 51 - 52)

End cap: Polyamide
(Zinc plated steel for ESA & ESB 51 - 52)

Bypass valve: (ESA) Polyamide

Magnetic core: (ESB) Syntherized magnetic material

Pressure

Collapse, differential: 100 kPa (1 bar)

Bypass valve

Setting: 30 kPa (0,3 bar) ± 10%

Working temperature

From -25° to +110° C

Flow rate

Qmax 600 l/min

Download

FMA – LFM

Multipurpose filter



Materials

Head: Aluminum alloy

Bowl: Cold formed steel

Seals: NBR Nitrile (FKM Fluoroelastomer on request)

Indicator housing: Brass

Pressure

Max working: 0,7 MPa (7 bar)

Collapse, differential for the filter element: 300 kPa (3 bar)

Working temperature

From -25° to +110° C

Flow rate

Qmax 600 l/min

Download

FSC – FSB

Suction filter

Materials

Housing: Aluminum alloy

FSC31 & FSC41
Cover & head: Aluminum alloy
Bowl: Polyamide

FSC71 & FSC81
Cover & housing: Aluminum

FSC51 & FSC61
Housing: Steel | Cover: Aluminum

Shut-off valve: Polyamide

Seals: NBR Nitrile
(FKM fluoroelastomer on request )

Indicator housing: Brass

Pressure

Collapse, differential for the filter element: 100 kPa (1 bar)

Working temperature

From -25° to +110° C

Flow rate

Qmax 500 l/min

Download

FSD – MSE

Suction filter

Materials

Cover & housing: Anodized aluminum alloy

For 61&62 only
Cover: Anodized aluminum alloy | Housing: steel

Bypass valve: Polyamide

Seals: NBR Nitrile
(FKM fluoroelastomer on request )

Indicator housing: Brass

Pressure

Collapse, differential for filter element (ISO 2941): 1 MPa (10 bar)

Working temperature

From -25° to +110° C

Flow rate

Qmax 700 l/min

Download

FSE – AMF

Suction spin-on filter

Materials

Head: Aluminum alloy

Spin-on cartridge: Steel

Bypass valve: Polyamide

Seals: NBR Nitrile (FKM fluoroelastomer on request )

Indicator housing: Brass

Pressure

Max working: 1,2 MPa (12 bar)

Collapse, differential for filter element: 400 kPa (4 bar)

Bypass valve

Setting: 30 kPa (0,30 bar) ± 10%

Working temperature

From -25° to +110° C

Flow rate

Qmax 75 l/min

Download

FSG – FAC

Tank side wall suction filter

Materials

Lid: Polyamide

Housing: Aluminum alloy

Seals: NBR Nitrile

Pressure

Collapse, differential for filter element (ISO 2941): 1 MPa (10 bar)

Working temperature

From -25° to +110° C

Flow rate

Qmax 70 l/min

Download

FAM

Suction strainer

Materials

Connector: Aluminum

Internal core: Zinc plated steel

End cap: Zinc plated steel

Pressure

Collapse, differential for filter element: 100 kPa (1 bar)

Working temperature

From -25° to +110° C

Flow rate

Qmax 600 l/min

Download

MSZ

Suction strainer

Materials

Connector: Polyamide

Internal core: Zinc plated steel

End cap: Zinc plated steel

Pressure

Collapse, differential for filter element (ISO 10771): 100 kPa (1 bar)

Working temperature

From -25° to +90° C

Flow rate

Qmax 600 l/min

Download
